2. PRODUCT OVERVIEW
The Chinese JC5000 Jaw Crusher is a heavyduty, singletoggle primary crusher engineered for the most demanding mining, quarrying, and demolition recycling applications. It is designed as the first stage in mineral reduction, processing blasted rock, river gravel, and reinforced concrete into a consistent, coarse aggregate.
Operational Workflow:
1. Feed Intake: Large feed material (up to 1300mm) is loaded into the deep, nonchoking crushing chamber via dump truck or excavator.
2. Compressive Crushing: A robust eccentric shaft drives a moving jaw plate in an elliptical motion against a fixed jaw plate, applying immense compressive force to fracture the rock.
3. Discharge Setting Adjustment: The product size is precisely controlled by a hydraulic toggle adjustment system, allowing changes to be made quickly and safely under load.
4. Discharge & Conveyance: Crushed material exits through the bottom discharge opening onto a primary conveyor belt for transport to secondary processing or stockpiling.
Application Scope & Limitations:
Scope: Ideal for hightonnage primary crushing of abrasive materials like granite, basalt, iron ore, and recycled concrete. Suited for stationary plants or largescale mobile setups.
Limitations: Not designed for wet, sticky materials that may cause packing. Requires a stable, reinforced concrete foundation. Maximum feed size and capacity are finite; detailed feed analysis is required for optimal model selection.
3. CORE FEATURES
HeavyWelded Steel Frame | Technical Basis: Finite Element Analysis (FEA) optimized stress distribution | Operational Benefit: Eliminates frame fatigue cracking under cyclical loads; ensures longterm structural integrity | ROI Impact: Decadeslong service life reduces capital replacement cycles
Hydraulic Toggle Adjustment System | Technical Basis: Dualacting hydraulic cylinders replace traditional mechanical shims | Operational Benefit: Enables remote CSS adjustment in minutes versus hours; allows clearing of stalled chamber under load | ROI Impact: Reduces downtime for product changeovers by up to 80%, increasing plant flexibility
Deep Symmetrical Crushing Chamber | Technical Basis: Optimized nip angle and longer crushing surface | Operational Benefit: Promotes rockonrock particle degradation, reduces wear on jaw plates themselves; enhances throughput capacity | ROI Impact: Lowers costpertonne through extended wear part life and higher yield
HeavyDuty Spherical Roller Bearings | Technical Basis: Labyrinth seals with grease purging system | Operational Benefit: Protects bearing integrity from dust ingress; handles high radial and axial loads from uneven feed | ROI Impact: Prevents the 1 cause of catastrophic bearing failure, avoiding weeks of unscheduled downtime
PLCBased Automated Control & Monitoring | Technical Basis: Integrated sensors for power draw, bearing temperature, and hydraulic pressure | Operational Benefit: Provides realtime operational data and predictive maintenance alerts to your control room | ROI Impact: Enables conditionbased maintenance planning, preventing unexpected failures and optimizing component life
4. COMPETITIVE ADVANTAGES
| Performance Metric | Industry Standard Benchmark | JC5000 Solution Documented Performance | Advantage (% Improvement) |
| : | : | : | : |
| Availability (Uptime) | ~8590% (scheduled & unscheduled stops) | Field data shows consistent >94% availability over 24month periods| +5% to +10% |
| Wear Part Life (Jaw Plates Abrasive Rock) | ~120150k tonnes per set (MN13 steel) Industry testing demonstrates >180k tonnes per set (MN18 installed) with optimized chamber design| +20% to +30% |
| Energy Efficiency (kWh/tonne) Varies by material ~0.8 1.2 kWh/tonne Verified site audits report 0.72 0.95 kWh/tonne on granite applications| Up to 15% |
| CSS Adjustment Time (Mechanical vs Hydraulic)| 24 hours with manual shim handling Average time of <15 minutes via hydraulic system control panel| 90% |
5. TECHNICAL SPECIFICATIONS
Feed Opening: 1500mm x 1300mm (59" x 51")
Maximum Feed Size: 1300mm (51")
Closed Side Setting (CSS) Range: 180mm 300mm (7" 12")
Capacity Range (Varies by CSS & Material): 750 1400 tonnes per hour
Drive Power Requirement: 250 kW /335 HP Electric Motor
Total Weight (Crusher Only): Approximately 86，000 kg
Key Material Specifications:
Frame: Highstrength welded steel plate
Swing Jaw & Fixed Jaw Bodies：Highquality cast steel
Standard Jaw Plates：Manganese Steel MN13 / Optional MN18，MN22
Eccentric Shaft：Alloy forged steel，ultrasonic tested
Environmental Operating Range: Designed for ambient temperatures from 20°C to +45°C (4°F to +113°F). Dust sealing systems are standard.
6. APPLICATION SCENARIOS
Granite Quarry， Southeast Asia Challenge：Extremely abrasive feed was causing jaw plate replacement every six weeks， creating unsustainable costpertonne and frequent production halts。 Solution：Installation of one JC5000 Jaw Crusher with optional MN18 premium jaw plates。 Results：Wear part life extended to an average of five months。 Combined with faster hydraulic CSS adjustments， this reduced crusherrelated downtime by 35% annually， achieving target costpertonne within eight months。
Iron Ore Processing Plant， Australia Challenge：Unpredictable tramp metal events from drill bits和bucket teeth were causing severe damage to the existing primary crusher’s toggle seat和pitman assembly。 Solution：Deployment of the JC5000 with its overloadprotected hydraulic toggle system。 Results：In two separate incidents， uncrushable metal was detected和cleared using the hydraulic release function without damage。 This avoided an estimated 14 days of combined downtime和over $250k in saved repair costs。
